DIG-DOG DSL20 Mini Skid Steer Loader 890 Kg

Item No.: DSL20
  • KEY SPECS::
    Operating Weight: 890 kg
    Bucket Capacity: 0.15 m³
    Power:23 hp/31 kw
Description Specification Attachments FAQ Review
Description

DIG-DOG DSL20 Diggit Mini Skid Steer Loader

Diggit Mini Skid Steer Loader | DIG-DOG DSL20

DSL20 Overview

The DIG-DOG diggit mini skid steer loader DSL20 is a multi-functional construction engineering equipment with a compact design, easy operation and suitable for various working environments. Its strong performance and versatility make it widely used in landscaping, manufacturing, construction sites, recycling, gardens, road construction, construction, farming and other industrial areas.

DSL20 Features & Benefits

The mini skid loader has a variety of convenient operating features, such as an operating handle that can handle walking, lifting, somersaults, etc., and two operating modes, servo and standard, making operation more convenient. Its plunger pump motor is stable, four-wheel drive adapts to various environments, and various types of foot pedals make operation safer and more convenient.

In addition, this diggit skid steer loader also has the characteristics of easy maintenance. For example, the oil outlet is located outside the car body, making it easy to replace the air filter, engine oil, engine filter, and spark plug. The rear guard plate is easy to remove, and the upper cover can be opened, etc. This makes maintenance easy and fast.

The stand-on mini skid steer loader can be equipped with a variety of accessories, and the accessories are interchangeable, about 40 types. The unified hanger quick-change and quick-connection makes the work more flexible and diverse. Its internationally renowned brand engines are stable and reliable, with guaranteed quality. At the same time, it is suitable for a variety of tires and track modes to choose from, making it more adaptable. Narrower body design, only 800mm wide, can easily pass through small spaces. The large fuel tank and lift keep it efficient during long working hours.

In general, this mini skid steer brings a lot of convenience to users by simplifying manual work and improving work efficiency. Compared with similar products, it has a higher lifting height and stronger adaptability. Choose the DIG-DOG DSL20 mini skid steer loader to make your engineering operations more efficient and convenient!
Specification
Diggit Mini Skid Steer Loader | DIG-DOG DSL20
DIG-DOG DSL20 Diggit Mini Skid Steer Loader
Operating weight 890kg
Max lifting Force(kg) 200 Kg
Bucket capacity 0.15 m3
Max lifting power 375 Kg
speed 0-5.5 Km/h
Rated power 21HP/23HP
Rotating speed(rpm) 3600
Noise(Db) ≤95
Hydraulic pressure(Mpa) 17
Max working height(A) 2115 mm
Max pin height (B) 1856 mm
Max dump height(C) 1460 mm
The highest point discharge distance(D) 388 mm
Bucket swing angle(β) 55°
Bucket unloading angle(γ) 30°
Opening-closing angle(θ) 25°
Angle of departure(α)
Total height (H) 1205 mm
The height from the ground(F) 90 mm
Wheelbase (G) 636 mm
No bucket length(J) 1752 mm
Total width (W) 1033 mm
Bucket width (K) 980 mm
Total length(L)(with bucket) 2206 mm
Turning radius (R) 1307 mm
Attachments
The DIG-DOG DSL20 diggit mini skid steer loader is not only a powerful machine, but also a highly versatile tool that can be easily accessorized to meet specific job requirements. With its vast array of interchangeable attachments, users can tailor the machine to their unique tasks, making it an invaluable addition to any construction or landscaping project.
One of the most notable features of the DIG-DOG DSL20 is its adaptability. Thanks to its standardized connection system, users can swap out attachments in mere minutes, transforming the machine into a multi-functional tool that can handle a wide range of applications. Whether it's digging trenches, moving materials, or clearing debris, this mini skid steer machine can handle it all with ease.
Moreover, the DSL20's accessories are designed to be durable and long-lasting, ensuring that they will stand up to the rigorous demands of construction work. From bucket attachments for earthmoving to augers for boring holes, the DL20S's attachments are built to perform and last.
In addition to its adaptability and durability, this mini skid steer is also known for its maneuverability. With its compact size and low center of gravity, the machine can navigate tight spaces with ease, making it an ideal choice for jobs where space is limited. Whether it's in a urban backyard or a confined construction site, the DSL20 can get the job done with ease.
With its interchangeable accessories, durability, and maneuverability, the DIG-DOG DSL20 diggit mini skid steer loader is a top-tier choice for anyone looking for a reliable and versatile tool for their construction or landscaping projects. Its adaptability and performance make it a go-to machine for any job, big or small.
Diggit Mini Skid Steer Loader | DIG-DOG DSL20
FAQ
Q: What are the advantages of your brand?
A: We manufacture our products locally. We use high quality materials & parts sourced from the very best in China.Our design team works closely with customers for any customized orders.

Q: How do l choose the right Skid Steer Loader?
A: *Consider What Size Skid Steer Will Get the Job Done Efficiently.
*Think About Your Job Surface.
*Assess the Lift.
*Look at the Controls.
*Assess Other Functional Features.
*Think About Attachments for Your Mini Skid Steer .

Q: Can you supply Skid Steer Loader attachments?
A: Of course, DIG-DOG can provide you with fully functional excavation attachments for your Diggit Skid Steer Loader.

Q: Which payment terms do you accept?
A: We can work on T/T bank transfer and 100% irrevocable L/C.

Q: what about the warranty time?
A:  12 months after shipment or 2000 working hours.

Q: What about the delivery time?
A: 20-45 days after receiving the deposit.
