Main parameters of DIG-DOG electric forklift 1T-3T |
||||||||
project |
unit |
CPD-10 |
CPD-1 5 |
CPD -20 |
CPD -30 |
|||
Rated lifting capacity |
㎏ |
1000 |
1500 |
2000 |
3000 |
|||
full length |
without fork |
mm |
2100 |
2350 |
2300 |
2450 |
||
With forks |
3170 |
3420 |
3370 |
3520 |
||||
full width |
1120 |
1200 |
1200 |
1200 |
||||
full height |
Can't lift mast height |
2080 |
2100 |
2100 |
2130 |
|||
overhead guard height |
2080 |
1990 |
1990 |
2070 |
||||
working height |
3720 |
3750 |
3750 |
3780 |
||||
wheelbase |
|
1580 |
1580 |
1720 |
||||
minimum distance ground clearance |
Mast lower end (empty/full) |
100 |
100 |
100 |
120 |
|||
Middle of frame (empty/full) |
130 |
130 |
130 |
180 |
||||
Gantry |
120mmC |
120mmC |
120mmC |
150mmH |
||||
Maximum lifting height without load |
3000 |
3000 |
3000 |
3000 |
||||
free lift height |
3000 |
3000 |
3000 |
3000 |
||||
Mast inclination (front/rear) |
(°) |
35° |
35° |
35° |
35° |
|||
The weight of the whole machine under the standard no-load condition |
㎏ |
1900 |
2500 |
2900 |
4300 |
|||
Maximum lifting speed without load (adjustable) |
mm/s |
110 |
160 |
150 |
120 |
|||
Full load maximum lifting speed (adjustable) |
130 |
190 |
180 |
140 |
||||
Minimum turning radius |
mm |
1500 |
1550 |
1700 |
2050 |
|||
No-load maximum running speed (adjustable) |
㎞/h |
12 |
14 |
14 |
14 |
|||
Full load maximum operating speed (adjustable) |
8 |
12 |
12 |
12 |
||||
Maximum grade ability with full load |
% |
15 |
15 |
15 |
15 |
|||
No-load maximum grade ability |
% |
20 |
20 |
20 |
20 |
|||
load center distance |
mm |
500 |
500 |
500 |
500 |
|||
Front Wheel Specifications |
/ |
16x6-8 |
650-10 |
650-10 |
23x9-10 |
